    Full Automatic Paper Plates Manufacturing Machine 1300*1400*1600mm

    Ask Lasest Price
    Brand Name : FECT
    Model Number : PF-400
    Price : USD 5,079/set
    Payment Terms : 30% T/T as deposit in advance, the balance by T/T after production
    Supply Ability : 50 sets per month
    Delivery Time : Within 30 days after deposit received
    • Product Details
    • Company Profile

    Full Automatic Paper Plates Manufacturing Machine 1300*1400*1600mm

    High Speed 50-70Pcs/min Manual Automatic Forming Paper plate making machine


    Packaging:

    Stable wooden package protects machine from strike and damage.
    Wound plastic film keeps machine out of damp and corrosion.
    Fumigation-free package helps the smooth customs clearance.
    The big size machine will be fixed in container without package.


    About Us

    High-Quality
    We elaborate every product to provide customers with the best service.
    Rich Experience
    We have rich experience to provide customers with the best products and services.
    Professional Team
    We have a professional team which can well feed customers to solver problems and provide better services.


    Configuration ♦


    NO.PART NAMESUPPLIER
    1RelaySchneider
    3Temperature ControllerShanghai Yatai
    4Time RelayOmron, Japan
    5CounterShanghai Yatai
    6Stainless Steel Heating PipeJiangsu Rong Dali
    8Counter SwitchShanghai Yijia
    9Normally Open PhotoelectricJapan, Omron
    10Solenoid ValveTaiwan Airtac
    11BearingHarbin
    12Temperature SensorWHENZHOU CHIN GROUP
    13Normally Closed PhotoelectricOmron, Japan
    14AC ContactorChint
    15Thermal RelayChint

    Technical Specification & configuration

    ModelPF-400
    Diameter of Paper Dish4-11inch (mould replacement)
    Capacity50-70Pcs/min
    Power Source220V 50HZ
    Total Power3KW
    Weight500Kg
    Dimension(L*W*H)1300*1400*1600mm
    Raw Material

    100-800g/m2(original paper, white paperboard, white cardboard,

    aluminum foil or others)

    Air SourceWorking pressure0.8Mpa Working air volume 1.5m3/min
    Main technical parameters of cylinder

    mpt-80-150-5t-15

    Air cylinder stroke: 150mm


    ♦Description ♦


    PF-400 Full Automatic Medium-Speed Paper Plate Forming Machine is developed and designed according to market demands. PF-400 reassembles the principle of combination of pneumatic and mechanical. Compared with the traditional automatic paper plate machine, PF-400 has higher dish ejecting rate ,and is easier to operate and maintain.


    Advantages

    Adopts high efficient pressurizing air cylinder, the maximum pressure can reach 5T, which compared with the oil pressure cylinder has faster and more environmental friendly advantages.


    widely used in productions which use original papers or aluminum foils as raw materials. Different specifications can be produced by changing the mould, round or square plates, etc.


    When you purchase machines, high-quality products, good service and favorable price should be your consideration. Most importantly, a reliable supplier will help you solve it, so chose us.

    We have won the trust and support from customs home and abroad. In order to provide better products and service, our company emphasis on the recruit of the international talents and has abundant technical power. It is well-worth mentioning that we always follow the principle:to serve our customers with a high sense of responsibility.Our workers are all high-motivated and our engineers take care of every detail and adopt strict factory quality standard with the philosophy "God is in the details.
