Digital 50m-60m/min 4 colors Paper Cup Bowl Flexo Printing Machine
In order to provide better products and service, our company
emphasis on the recruit of the international and has abundant technical power. It is well-worth mentioning that we always follow the principle: to
serve our customers with a high sense of responsibility.Our workers are all high-motivated and our engineers take
care of every detail and adopt strict factory quality standard with
the philosophy "God is in the details". We have won the trust and support from customs home and abroad.
Description
1. The paper cup and bowl flexography printing machine also can
combine with other printing machine like Gravure printing and
screen printing machine, for exquisite label printing work.
2. 4 color paper cup bowl flexo printing machine is fully can
complete the whole process of feeding, printing, varnishing,
drying, laminating, die-cutting, rewinding and sheeting. It is high
economic benefit and non-polluting ink.
3. It is the ideal choice for factory to print many kinds of paper
cup, coffee cup, paper bowl, paper box, etc
4. 4 color paper cup bowl flexo printing machine belongs to
flexographic printing machine. The biggest reason why it used for
high-grade paper cup printing is its ceramic anilox cylinder, which
make printing on paper more precise and finer.
5. At last, the label printing press is environmental because of
its UV ink or Water ink, non-toxic ,colorless and tasteless, accord
with sanitary requirement.
6. 4 color paper cup bowl flexo printing machine is very suitable
for standardization. Flexo printing machine through the many plates
holes in cylinder to convey the ink, once you choose the right
roller in the printing process, the color change little, to some
extent,can reduce the dependence on operator experience. And
through this ink transmission, color is well-distributed.
♦Features♦
1. Equipped with web guide for tracking.
2. Adopt high quality ceramic anilox cylinder to transfer the ink.
3. The main motor is adopted the import stepless, regulation of
frequency conversion.
4. Each printing unit equips with IR dryer.
5. Unwinding adopts auto tension controller.
6. Each printing unit adopts 360° adjustment, it can independently
gear and loosen,so other printing units can continue to print.
7. The printing unit can register in 360degress;each printing unit
can mesh roller and improve the printing efficiency.
8. The ink rollers will be separated from the printing rollers,and
keep running when the machine stops.
9. Unwinding is controlled by magnetic powder brake and rewinding
is controlled by magnetic inverter motor .
10. The machine can finish material-feeding, printing,rewinding in
a lump.It is an ideal machine for printing note and top-grade paper
cup.
♦Technical parameters♦
| Printing speed | 50m-60m/min |
| Printing color | 4 colors (1/2/3/4/5/6/7/8 color for option) |
| Print max width | 850mm |
| Unwind roll width | 860mm |
| Unwind roll diameter | 1300mm |
| Rewind roll max diameter | 1300mm |
| Printing length | 175-370mm |
| Registering accuracy | ±0.15mm |
| Voltage | 36kw |
| Air press | 0.6MP |
| Weight | 4500kg |
| Dimension | 4500X1800X2250mm |
♦Standard Configuration♦
1) 2 sets Printing roller
2) 2 sets ceramic anilox roller (made in shanghai)
3) 5 group * 3 sets printing rollers = 15 pcs (buyer offer
dimension)
4) Transducer(2 pcs)
5) One unwinding tension controller
6) One rewinding tension controller
7) 1 pcsElectromagnetism valve
8) Main Motor
9) Button
10) All low-tension electrical
11) Web guiding for correcting edge
FAQ
Q1: Are you manufacturer or trading company?
A: We have our own factory and export team, welcome to visit our
factory, we can pick you up at the airport.
Q2 : Do you have relevant certificate?
A: Yes, so far, we have CE, ISO, etc. we also can issue CO, Form E,
etc if you need.
Q3 : What payment terms are accepted?
A: TT(Telegraphic Transfer), Western Union, MoneyGram, LC, etc.
Q4 : Do you inspect the finished machines?
A: Sure, we test every machine before packing and provide test
video.
Q5 : When can the machine be shipped after order is placed?
A: It depends on machine model and quantity, some stock machines
can be shipped within 3 working days after payment, other
customized machines start production after deposit arrived, please
contact our staff for detail info.
Q6: How about the warranty and after-sale service?
A: Our machines have two years warranty and lifetime technical
support. Help is always just one call or email, and then we can
provide a suitable solution within 8 hours after analyzing and
estimating the problem. Remote training and door-to-door service is
available.
Packaging:
Stable wooden package protects machine from strike and damage.
Wound plastic film keeps machine out of damp and corrosion.
Fumigation-free package helps the smooth customs clearance.
The big size machine will be fixed in container without package.
