180 M / Min Double Side Extrusion Laminate PE Coating Machine For
Paper
210m / Min Single Side Film Non Woven Paper Pe Extrusion Coating
Laminating Machine could accept LDPE,PP,EVA,EAA, etc. lamination grade material,Use
for film(BOPP,BOPET,CPP,CPE, etc) Paper,Aluminum Foil,Non-woven,
etc. as base material for compounding lamination.Widely used in
medical packaging,food packaging,office packaging,industrial
packaging and other packaging.
♦Technical Parameters♦
| Screw diameter | φ105mm |
| L/D | 33:1 |
| Finished film widts | 800-1700mm |
| Lamination thickness | 0.01-0.10mm |
| Usable resin | LDPE, LLDPE, PP, EVA, EAA |
| Design line speed | 210m/min |
| Max extrusion capacity | 330kg/h |
| Main motor power | 55kw |
| Diameter of main unwinding | 1300mm |
| Diameter of winding | 1300mm |
| Power supply | 380/3/4/50(Volt/Ph/Line/Hz) |
| Working Speed | 170-180m/min, based on detail material |
| Roller Width | 1700 mm |
| Extrusion Material | LDPE PP EVA EMAA, EAA And Other Lamination Material |
| Extrusion resin thickness | ±5% |
About SJ105/33 Single Screw Extruder
| Extrusion Capacity | For LDPE(MI=4～7,Melting Temperature 330ºC),Max Extrusion Capacity
330kg/h,Precise Capacity depend on the material and technology
process. |
| Screw and Barrel | 1)Dia:φ105mm,L/D 33:1 2)Screw & Barrel Material:38CrMoAlA 3)Antiseptic Treatment:Nitride hard chromium plating processing and
surface protection: 4)Nitride Depth:0.4-0.7mm,brittleness≦Lv2 5)Heater:Air Cooling Cast Iron Heater 6)Heating Power:60kw 7)Heating Control:6 Zone |
Option: Add Shaftless Unwinder with Auto Splicer
