    PLC Touch Screen Single Side EVA PE Coating Machine For Paper Cups

    Ask Lasest Price
    Brand Name : Fect
    Model Number : PF-1300
    Certification : CE
    Price : USD 80000-USD 90000 PER SET
    Payment Terms : T/T, L/C, Western Union, Money Gram, or Credit card.
    Supply Ability : 30 Sets Per Month
    Delivery Time : 60 working days after received the deposit
    • Product Details
    • Company Profile

    PLC Touch Screen Single Side EVA PE Coating Machine For Paper Cups

    Single side pe coating extrusion laminating machine for paper cup
    Single side pe coating extrusion laminating machine for paper cup is adopts the casting technology, laminate the two layers materials together. made by compounding fluid, plastic film, woven cloth or aluminum foil into double layer, three layer or multi-layer new materials, which are used for packaging products of cement, chemicals, forage, food, medicine, adhesive tape cloth, plastic coating paper cups and fast food boxes, etc.

    ♦Technical Parameters♦

    Screw diameterφ105mm
    L/D33:1
    Finished film widts800-1300mm
    Lamination thickness0.01-0.10mm
    Usable resinLDPE, LLDPE, PP, EVA, EAA
    Design line speed210m/min
    Max extrusion capacity330kg/h
    Main motor power55kw
    Diameter of main unwinding1300mm
    Diameter of winding1300mm
    Overall size10000×12000×3200 mm
    Power supply380/3/4/50(Volt/Ph/Line/Hz)
    Working Speed180m/min, based on detail material
    Roller Width1700 mm
    Extrusion Material

    LDPE PP EVA EMAA, EAA EMA

    And Other Lamination Material

    Extrusion resin thickness±5%

    PLC Touch Screen Single Side EVA PE Coating Machine For Paper CupsPLC Touch Screen Single Side EVA PE Coating Machine For Paper CupsPLC Touch Screen Single Side EVA PE Coating Machine For Paper Cups

    PLC Touch Screen Single Side EVA PE Coating Machine For Paper CupsPLC Touch Screen Single Side EVA PE Coating Machine For Paper Cups

    PLC Touch Screen Single Side EVA PE Coating Machine For Paper Cups


    ♦Features♦


    1 Entire machine adopt PLC touch screen,PLC control converter,drive by Motor.


    2 Extrusion Laminating Machine use the casting technology, laminate the two layers materials together.


    3 This machine is made by compounding fluid, plastic film, woven cloth or aluminum foil into double layer,


    4 Three layer or multi-layer new materials, which are suitable for packaging products of cement, chemicals, forage, food, medicine, adhesive tape cloth, plastic coating paper cups and fast food boxes, etc.


    ♦FAQ♦

    Q1: Are you manufacturer or trading company?

    A: We have our own factory and export team, welcome to visit our factory, we can pick you up at the airport.


    Q2 : Do you have relevant certificate?

    A: Yes, so far, we have CE, ISO, etc. we also can issue CO, Form E, etc if you need.


    Q3 : What payment terms are accepted?

    A: TT(Telegraphic Transfer), Western Union, MoneyGram, LC, etc.


    Q4 : Do you inspect the finished machines?

    A: Sure, we test every machine before packing and provide test video.


    Q5 : When can the machine be shipped after order is placed?

    A: It depends on machine model and quantity, some stock machines can be shipped within 3 working days after payment, other customized machines start production after deposit arrived, please contact our staff for detail info.


    Q6: How about the warranty and after-sale service?

    A: Our machines have two years warranty and lifetime technical support. Help is always just one call or email, and then we can provide a suitable solution within 8 hours after analyzing and estimating the problem. Remote training and door-to-door service is available.
