210m/min Automatic Single Side Extrusion Lamination PE Coating
Paper Machine
♦Description♦
1300mm automatic single side extrusion lamination pe coating paper
machine is at the forefront of technology, boasting a high
manufacturing quality with components suitable for processing
paper, nonwoven fabric ,aluminium and so on. we has focused on high
performance extruders with special screw design for a wide range of
materials like PP, LDPE, LLDPE, PP, EVA, EAA. With customized
solutions including different layers, sizes and die widths.
♦Features♦
1, Entire machine data can set in PLC touch screen,PLC control
converter,drive by Motor.
2, Extrusion Laminating Machine adopts the casting technology,
laminate the two layers materials together.
3, Made by compounding fluid, plastic film, woven cloth or aluminum
foil into double layer,
4, Three layer or multi-layer new materials, which are used for
packaging products of cement, chemicals, forage, food, medicine,
adhesive tape cloth, plastic coating paper cups and fast food
boxes, etc.
♦Technical Specification♦
| Screw diameter | φ105mm |
| L/D | 33:1 |
| Finished film width | 800-1600mm |
| Lamination thickness | 0.01-0.10mm |
| Usable resin | LDPE, LLDPE, PP, EVA, EAA |
| Design line speed | 210m/min |
| Max extrusion capacity | 330kg/h |
| Main motor power | 55kw |
| Total power | 165kw |
| Diameter of main unwinding | 1300mm |
| Diameter of winding | 1300mm |
| Weight | 15 ton |
| Overall size | 10000×12000×3200 mm |
| Power supply | 380/3/4/50(Volt/Ph/Line/Hz) |
| Working Speed | Max. 180m/min, based on detail material |
| Roller Width | 1700 mm |
| Extrusion Material | LDPE (MFR=4～15) PP (MFR=15～25) EVA (VA:5～20%, MFR=3～16) EMAA, EAA (AA: 4～12%, MFR=5～14) EMA (MA: 5～20%, MFR=5～9) And Other Lamination Material |
| Extrusion resin thickness uniformity | ±5% |
| Heating | Electrical Heating |
| Temperature Control | Temperature Controller |
| Base material | Paper(35～425g/m²),Mainly for 40～120g/m² |
| Machine Control | PLC Programmable Controller,Touch Screen Control |
| Drive Motor | Ac vector frequency conversion motor(Siemens) |
| Converter | AC Vector Converter(Inovance) |
| Total Power | Loading Power 165kw(Using Power 85～100kw) |
| Cooling Water Supply | Temp. 16～25℃,Flow Rate 80m³/h,Water Pressure ≧2kg/cm² |
| Air Supply | Air Pressure ≧ 6kg/cm²,Air Consumption 15m³/h |
♦ Accessory system (Prepared by Buyer)♦
- Electrical system
- Cooling system
- Air supply system
- Waste discharge system
♦The following project should prepared by buyer♦
- Machine running Plant
- Electrical Box to machine elcetrical cabinet
- Water project in-out from this machine
- Air supply in-out related to this machine
- Waste discharge from mould and corona
- Rolling up and down Tools
- Others not listed in agreement
Additional statement: As machine is improving every year, machine configuration may
change accordingly.
