PLC Control Coated Paper Roll Slitting Machines For Lunch Food
Takeaway Boxes
PLC Control Coated Paper Roll Slitting Machines is suitable for
slitting and rewinding of various materials, such as 30-400gsm
kraft paper, white cardboard, coated paper, PVC film, non-woven
Material. It is widely using in the paper bags manufacturing,paper
cups bottom manufacturing,paper tube manufacturing and other paper
products manufacturing industry.
Features for paper slitting machines
1) This machine adopts PLC touch screen control.Three motor servo
control and automatic taper tension, central surface reeling.
Frequency control for main motor, keeping speed up and stable
operation.
2) It has the functions of auto metering, automatic alarm, etc.
Adopt A and B pneumatic shaft structure for rewinding,easy for
loading and unloading.
3) It adopts photoelectric automatic error correction adjustment
system for unwinding, anomalistic materials will be easy slit.
4) Equipped with automatic waste film blowing device.
5) Automatic material loading by pneumatic, matched with air.
Specification for paper slitting machines
| Model | PFA-1300 | PFA-1600 |
| Max. width of unwinding | 1300mm | 1600mm |
| Slitting thickness | 30g/m2~400g/m2 |
| Raw material Unwinding Diameter | φ1400mm |
| Raw rewinding max. diameter | φ1000mm |
| Slitting Max.Width | 30-1600mm |
| Rewinding air shaft diameter | φ76mm/ 2pcs(152# can choose) |
| Rewinding air shaft quantity | 2pcs |
| Correct Precision | | ±1mm |
| Slitting Precision | | ±0.2mm |
| Slitting Speed | 50-380m/min |
| Total Power | 22kw | 26kw |
| Machine Size | 4500×3300×1900mm(L*W*H) | 4500×3800×1900mm(L*W*H) |
| Machine Weight | 4000kg | 4500kg |
| Machine cove color | main white |
| Air supply | need air compressor |
| Power supply | 3phase 4 wire switch; 380V 50HZ |
Details for paper slitting machines
After Sale Service
1) 1 year warranty service.
2) Free replacement of parts within 1 year (free shipping).
3) Parts are provided free of charge within 2 years, but no free
shipping.
4) We provide Operation & Maintenance CD.
5) When there is a problem with the machine, please take a video of
the problem and send it to us.
6) We will arrange professionals to help you deal with it through
video or document tutorials.
FAQ
Q1: Are you manufacturer or trading company?
A: We have our own factory and export team, welcome to visit our
factory, we can pick you up at the airport.
Q2 : Do you have relevant certificate?
A: Yes, so far, we have CE, ISO, etc. we also can issue CO, Form E,
etc if you need.
Q3:How can I find the most appropriated machine for my material?
A:You can tell us the parameters of your material,
Material Name:
Raw width of the material:
Thickness of the material:
Slitting width of the material:
Rewinding diameter:
Unwinding diamater:
Inner core diameter:
then we can recommend you the most suitable machine with best price
for you.
Q4:Will you Teach me to operate the machine?
A:First ,our machine is stable and easy to operate by one man ,what
you do is just learn some basic thing like loading the jumbo roll
paper,start the machine and cutting the paper.And we will sent you
manual and video ,we suggest you to come to visit our factory to
learn more thing by yourself.
Q5 : What payment terms are accepted?
A: TT(Telegraphic Transfer), Western Union, MoneyGram, LC, etc.
Q6 : Do you inspect the finished machines?
A: Sure, we test every machine before packing and provide test
video.
