    ODM Single Double Face No Glue Paper Straw Making Machine Eco Friendly

    Ask Lasest Price
    Brand Name : Fect
    Model Number : PF-80 paper straw machine
    Certification : CE
    Price : FOB US $27200.00 - 27300.00 / Set
    Payment Terms : L/C, T/T, Western Union, MoneyGram
    Supply Ability : 90 sets per month
    Delivery Time : within 35 working days after payment confirmed
    • Product Details
    • Company Profile

    ODM Single Double Face No Glue Paper Straw Making Machine Eco Friendly

    Eco Friendly Single Double Face No Glue Environmental Paper Straw Machine


    paper straw machine


    This Machine is suitable for producing different sizes of paper straws and very small paper tubes. It adopted with PLC controller; main motor is equipped with variable frequency speed regulation; touch screen man-machine interface. Easy for parameters setting & operating. Cutting section adopted with numerical multi-blades cutting system. Servo synchronous tracking cutting system makes it higher precision and multi-blades cutting makes it higher efficiency. Machine body and main spare parts made by stainless steel instead of painting. Ensure the hygiene and environmental protection of the products.


    Eco Friendly Single Double Face No Glue Environmental Paper Straw Machine


    1. Adapted to PLC and human-machine interface, the paper straw machine is super easy to operate.
    2. 2. Adopting high quality electrical parts from world famous brands. The straw machine has a long service life.
    3. With stainless steel body and protective cover. Finished paper straws are clean and safe.
    4. Equipped with infrared dryer to improve the dryness and hardness of the paper straws.
    5. The multi-blade cutting system ensures high productivity. It is easy to adjust the cutting distance with these gas cylinders.


    Technical Parameter of paper straw machine


    Surace Layer paper roll thickness 60gsm, middle & inner layer is 120gsm
    If you need printed paper straw, only need to print the 60gsm thickness paper roll.
    Paper Roll can be coated with Wax as per your requirements.
    The proportion of paper roll and glue is 1000kgs paper roll: 150kgs glue.
    One ton paper roll can do around 850000pcs of paper straw.
    It is water base glue, must be food grade.
    Technical Parameter
    Paper Layer3 layers
    Inner Diameter3.5-12 mm
    Min. Length90 mm
    Wall Thickness0.5-1.5
    SpeedUp to 100 m/min.
    Rewinding NosesTwo noses/single belt
    Cutting methodPneumatic blades
    Gluing waySingle/Double face or no glue
    Length fixationEncoder
    Way of shaft fixingPushing
    Speed controlServo
    Operator1 person
    Power input3*380V
    Measurement & Weight
    Main machine size3511*1265*1800mm
    Area space5000*5000mm
    Wheel hub diameter215 mm
    Wheel hub height125 mm
    Min. tread320 mm
    Max. tread500 mm
    Weight1700kgs

    Drive system
    Main power3.0 kw
    Max. Rotate speed of wheel hub200 r/min
    Output torque68 N.m
    Drive of wheel hub2 wheel drive
    BearingNSK

    Control system
    PLC ControllerDelta
    Man-machine interfaceWeinview
    Servo systemDelta
    ActuatorSchneider
    Signal componentsOmron
    Pneumatic componentAirtac
    Synchronism controlServo Flying Cutting system
    Synchronous tracking cutting systemElectronic cam flying shear servo system

    Outfit assembly
    Tube holderStandard
    Belt angle adjustingHand wheel adjustment
    Belt tension adjustingHand wheel adjustment
    Stop when paper breakStandard
    Auto glue feedingDiaphragm pump
    LubricationElectric roller
    Paper tension controlConstant tension control
    Paper reel stand typeAutomatic paper receiving
    BeltFilm baseband

    Enclosed component
    Mandrel3 pcs
    Belt5 pcs
    Tools1 set
    Air compressoroptional
    Automatic cutter adjustment deviceoptional
