10kw 150-200 times/min Automatic Paper Cup Punching printing cup
making machine
Cutting size: 3-32 oz
Speed: 170-230times/min (600-1000pcs/min)
Roll diameter: Max 1400mm
Roll width: Max 850mm
Supply Ability: 20 Set/Sets per Month 850 paper cup blank printing die cutting
machine
Quality Guarantee: One year warranty and lifelong technical service, Inspection
before delivery is available. The above clause is ONLY effective
under the machine is being properly used, any artificial misuse or
destroy purposely is not within the limit of Quality Guarantee.
♦Features♦
1. Unwinding, web guiding, printing, IR drying, die-cutting, waste,
rewinding, trimming, rewinding, can be finished in one process
2. The rubber roller can break away automatically while parking,
and running at alow speed, in order to avoid ink being ary.
3. Adopt the anilox roller to spread ink
4. Each printing unit have one IR drier
5. Unwinding and rewinding are controlled by magnetic power brake,
clutch (or by automatic tension controller of Mitsubishi, made in
Japan)
6. The main motor is adopted the import stepless, regulation of
frequency conversion
7. Each printing unit adopt 360 for registration
When you purchase machines, high-quality products, good service and
favorable price should be your consideration. Most importantly, a
reliable supplier will help you solve it, so chose us.
We have won the trust and support from customs home and abroad. In
order to provide better products and service, our company emphasis
on the recruit of the international talents and has abundant technical power. It is well-worth mentioning that we always follow the principle:to
serve our customers with a high sense of responsibility.Our workers are all high-motivated and our engineers
take care of every detail and adopt strict factory quality standard
with the philosophy "God is in the details".
♦Technical parameters♦
| Cutting speed | 150-200 times/min |
| Max. web width | 860mm |
| Max. unwind diameter | 1300mm |
| Max. cutting size | 850mmX450mm |
| Precision | ±0.15mm |
| Voltage | 380V± |
| Power | 10kw |
| Oil lubrication | Manual |
| Weight | 3000kg |
| Dimension | 3000x1400x2000mm |
FAQ
Q: Do you factory accept customized configuration?
A: Yes. About electric parts, you could choose SIEMENS, Schneider,
Delta and etc. For the machine device, web guiding, video monitor,
pneumatic-unwinding loader,electric-rewinding unloader, slitting
station rotary die-cutting station, lamination and waste rewinding
are optional. For the specific combination, pls contact us.
Q: How does your factory do regarding quality control?
A: Quality is the priority. We always regard great importance to
quality controlling from the very small thing (even a small screw
we will choose the best quality) from the beginning.
Q: What is your after-sales service?
A: Our after-sales service is first class. We have a powerful team
to help you solve problems. The Warranty is one year and if the
machine is damaged by natural, not by a human, we can send the new
parts to you for free.
Q: What are the terms of payment you accept?
A: 30% T/T in advance, 70% T/T balance before delivery. We also
accept L/C and Western Union.
Packaging Details
Wooden Case/ 850 paper cup blank punching die cutting machine
| Package detail | Wooden case/ paper cup blank printing die cutting machine |
| Package size | 39m×18m×2.2m |
| Gross weight | 3500kg |
Stable wooden package protects machine from strike and damage.
Wound plastic film keeps machine out of damp and corrosion.
Fumigation-free package helps the smooth customs clearance.
The big size machine will be fixed in container without package.
Product Description
This CQ850 paper cup blank punching die cutting machine is fully
automatic with paper feeding, cutting and rewinding function.
♦Application♦
This is an ideal machine for paper cup, paper bowl factory to cut
many kinds of the paper cup, coffee cup, paper bowl, paper box,
etc.
