    140-170 Pcs/Min Paper Cup Making Machines 2.46*1.62*1.78m Tea Cup Maker Machine

    Ask Lasest Price
    Brand Name : FECT
    Model Number : PF-OC100
    Certification : CE
    Price : USD$ 50795/ set
    Payment Terms : 30% T/T as deposit in advance, the balance by T/T after production
    Supply Ability : 500 Set/Sets per Month paper cup making machine
    Delivery Time : Within 45 working days after deposit received and mold details confirmed
    • Product Details
    • Company Profile

    140-170 Pcs/Min Paper Cup Making Machines 2.46*1.62*1.78m Tea Cup Maker Machine

    4-16 oz 140-170 pcs/min Full Automatic Paper Tea Coffee Cup Forming Machine


    Technical Specification

    TypePF-OC100
    Cup size:4-16 oz (other customized size)
    Cup material

    170-380 gsm single or double PE/PLA/ coated paper

    aluminum foil paper

    (0.25-0.5 mm)

    Production capacity140-170 pcs/min
    Power source:

    380V 3- phase 50HZ 34kw

    Running consumption is 14kw

    (please inform us your power in advance)

    Air Supply0.6 Mpa,(running consumption 0.4Nm3/min)
    Dimension2.46*1.62*1.78 m
    Weight3000KG
    H.S code for customs8441309000

    PF-OC100 features full servo driven technology throughout the entire machine. Servo drives work independently to control each station with remarkable accuracy and work together to coordinate the synchronized motion. It replaced the market almost gear / chain transmission and cam design paper cup machine. It provides flexibility, speed, affordable capital cost and low maintenance.


    Advantage

    Paper cup blank shuttle& rotary placer mechanism

    PF -150 adopts the most advanced blank shuttle & rotary placer mechanism, replaced traditional up and down movement suction feeding way to avoid paper move problem. Rotary placer mechanism pick and put paper more stable, which ensure the paper feeding to cup body sealing part more smoothly and steady.


    Paper cup bottom and top forming driven mechanism

    Adopts crankshaft and servo motor control instead of traditional cam transmission, no oil lubricant, which solved the negative effects of cam and bearing wearing and impacting while machine running at high speed. This breaks through the traditional paper cup machine must using cam to control the lifting and time.


    Paper cup servo indexing mechanism

    PF -150 uses servo indexing mechanism, replaced the traditional paper cup machine which uses the Geneva indexing mechanism. It's new in paper cup machine manufacture field. Servo indexing mechanism no need oil lubricant, no need maintenance, easy installation. It is more flexible for the machine self- adjustment while machine change the speed, even machine working in worse running conditions.


    Paper cup bottom sealing process

    PF -150 changed the working procedure of bottom sealing. First Leister hot air preheating the cup body, then the cup bottom paper coming. This procedure makes fast sealing while the hot and cold paper touched each other. Then the second Leister hot air heating the bottom to go next knurling process. It makes the paper cup bottom seal more firmly while machine running at high speed. Traditional paper cup machine they do the double bottom heating after bottom paper come to the cup body. PF -150 new design makes the bottom knurling much better.


    Configuration♦


    Medium PLC (AM403-CPU1608TN+ module)Inovance
    10-inch touch screenInovance
    Inverter (MD200)Inovance
    Servo motorInovance
    EtherCat network cable (CAT6A industrial grade)Customize
    Power switchTaiwan MEAN WELL
    Reducerdomestic customization
    Proximity switchAutonics
    Photoelectric switchAutonics
    Steam source pressure protectorAutonics
    ButtonAutonics
    Remote controlDomestic
    Circuit breakerSchneider, France
    AC contactorSchneider, France
    Small relay (including base)Izumi, Japan
    Terminal blockPhoenix, Germany
    Power phase sequence protectorSemute
    Detection SystemInovance

    ♦Features♦

    1) This machine uses servo indexing mechanism, replaced the traditional paper cup machine which uses the Geneva indexing mechanism. It's new in paper cup machine manufacture field.


    2) Adopts the most advanced blank shuttle & rotary placer mechanism, replaced traditional up and down movement suction feeding way to avoid paper move problem.


    3) Adopts crankshaft and servo motor control instead of traditional cam transmission, no oil, lubricant, which solved the negative effects of cam and bearing wearing and impacting while, machine running at high speed.
