    950MM Envelopes Paper Cup Die Cutting Machine ODM Automatic Paper Punching Machine

    Ask Lasest Price
    Brand Name : Fect
    Model Number : PF-970
    Certification : CE
    Price : USD 31000.00 - 33000.00 per set
    Payment Terms : L/C, T/T, Western Union, MoneyGram
    Supply Ability : 90 sets per month
    Delivery Time : within 30 working days after payment confirmed
    • Product Details
    • Company Profile

    950MM Envelopes Paper Cup Die Cutting Machine ODM Automatic Paper Punching Machine

    950 MM Width Custom Automatic Punching envelopes Paper Cup Die Cutter


    Paper Cup Die Cutting Machine


    It adopts micro-computer, human-computer control interface, servo positioning, alternation current frequency converter,
    automatic counting, manual pneumatic lock plate, photoelectric correcting deviation system, electromagnetic clutch, centralized oil lubrication, overload protection and distinctive gearing,so it guarantees smooth operations of returning paper and feeding paper, precise positioning and orderly withdrawing.This die cutting machine used to die cut pe coated paper, normal paper, corrugating paper and plasitc material, it applied to paper cup, paper box, medical package, wine package, food packages etc.


    950 MM Width Custom Automatic Punching Envelopes Paper Cup Die Cutter


    1. Paper conveyed by servo motor to ensures steady and accurate conveying. photoelectricity sensor checks the color code of printing to ensure fix the paper position accurately.

    2. Electric control system uses PLC and HMI. Equipped with safety refinements to make acoustic - optical alarming and auto stop when some faults.

    3. Worm wheel and worm transmission system ensures the powerful and steady pressure;It is very convenient and accurate to adjust pressure through HMI.

    4.Lubricating with oil circulation and alarming when lack of oil to ensure smooth running and prolong the machine life.

    5. Pneumatic locking system to make sure cutter not fall down


    Technical parameters of paper cup die cutting machine


    ModelMQ970*550
    Max cutting area950*510mm
    Cutting precision±0.2mm
    Paper gram weight100-500g
    Production capacity90-180times/min
    Max die cutting speed10800pcs/min
    Max roll feeding width970mm
    Max unwinding diameter1600mm
    Max cutting pressure320T
    Max die cutting width950mm
    Total power12KW



    FAQ of paper cup die cutting machine

    Q1: Are you a manufacturer or a trading company?

    A: We have our own factory and export team, welcome to visit our factory, we can pick you up from the airport

    Q2:: Do you have relevant certificate?

    A: Yes, so far we have CE, ISO, etc. We can also issue CO, Form E etc. if you need it.

    Q3: Do you inspect finished machines?

    A: Yes, we have QC department, they will inspect each machine before packing, and provide testing video to make sure there is no problem of the machines.

    Q4: What payment terms are accepted?

    A: TT (Telegraphic Transfer), Western Union, MoneyGram, LC, etc.

    Q5: When can the machine be shipped once the order is placed?

    A It depends on the machine model and quantity, some machines in stock can be shipped out within 3 working days after payment is cleared, other customized machines start production after deposit arrives, please contact our team for information detailed.

    Q6: What about warranty and after-sales service?

    A: Our machines have a two-year warranty and lifetime technical support. Help is always just a call or email away, then we can provide a suitable solution within 8 hours after analyzing and estimating the problem. Remote training and door-to-door service are available
