400x350mm MQ970 Carton Box Die Cutting Machine For Paper Box

    Buy cheap 400x350mm MQ970 Carton Box Die Cutting Machine For Paper Box from wholesalers

    Buy cheap 400x350mm MQ970 Carton Box Die Cutting Machine For Paper Box from wholesalers
    • Buy cheap 400x350mm MQ970 Carton Box Die Cutting Machine For Paper Box from wholesalers
    • Buy cheap 400x350mm MQ970 Carton Box Die Cutting Machine For Paper Box from wholesalers
    • Buy cheap 400x350mm MQ970 Carton Box Die Cutting Machine For Paper Box from wholesalers

    400x350mm MQ970 Carton Box Die Cutting Machine For Paper Box

    Ask Lasest Price
    Brand Name : FECT
    Model Number : MQ970
    Certification : CE
    Price : USD$ 46, 619/ set
    Payment Terms : 30% T/T as deposit in advance, the balance by T/T after production
    Supply Ability : 30 Set/Sets per Month Die Cutting Machine
    Delivery Time : Within 35 days after deposit received
    • Product Details
    • Company Profile

    400x350mm MQ970 Carton Box Die Cutting Machine For Paper Box

    200 times/min MQ970 Cake Small Paper Carton Lunch Box Die Cutting Machine for Paper box


    Application:
    Good price automatic hamburger cake small paper carton lunch box die cutting machine for paper box is suitable for creasing, die-cutting various cigarette case, medicine case, envelopes, paper cup, food paper box, paper bowl, gift bags and various paper producuts.It can finish paper embossing, creasing, die cutting and automatic collectiion all steps in one time.

    package detailWooden case/Good price automatic hamburger cake small paper carton lunch box die cutting machine for paper box
    Package size4.8*3*2.6m(L*W*H) (L*W*H)mm
    Gross weight8T

    Packaging:
    Stable wooden package protects machine from strike and damage.
    Wound plastic film keeps machine out of damp and corrosion.
    Fumigation-free package helps the smooth customs clearance.
    The big size machine will be fixed in container without package.


    Specification:

    ModelMQ970
    Max speed200 times/min
    Die cutting precision±0.1mm
    Paper thickness80-2000g
    Max. Die cutting pressure320T
    Max. Die cutting size1120*640mm(W*L)
    Min. Die cutting size400*350mm(W*L)
    Max unwind paper roll diameter1600mm
    Power16kw 380V 3P
    Dimensions2500*1450*3300(mm)
    Machine weight3500kg



    Feature:
    1. Unwind air shaft controlled by pneuamtic brake, hydraulic loading

    2. Servo motor control EPC device
    3. Paper moving forward controlldy by servo motor
    4. It can automatically fold and flatten paper which is near paper core and adjust different paper folding angle

    5. Photoelectric eye trace paper to ensure synchronization of paper feeding speed and die cutting speed
    6. Pneumatic locking system to make sure cutter not fall down
    7. Die cutting cutter plate and cutter frame can be taken out simultaneously to save plate-changing time
    8. When paper is in jam, it will alarm and machine stop automatically
    9. Finished paper will pile up automatically, lower down automatically to keep piling height unchanged
    10. The whole machine is controlled by PLC and touch screen which is convenient, we can set paper tension, paper feeding length, paper counting and automatic stop


    About Us
    High-Quality
    We elaborate every product to provide customers with the best service.
    Rich Experience
    We have rich experience to provide customers with the best products and services.
    Professional Team
    We have a professional team which can well feed customers to solver problems and provide better services.


    Quality Guarantee: One year warranty and lifelong technical service, Inspection before delivery is available. The above clause is ONLY effective under the machine is being properly used, any artificial misuse or destroy purposely is not within the limit of Quality Guarantee.
    Installation and Debugging: we can send technician for installation and training at the cost of buyer (visa, round tickets, eating, accommodation in his country and salary 100 USD /day).

    If you have any question, you can consult us. We will help you solve it.
    If you prepare to place a big order, We will give you a favorite price.
