Double Wall Hot And Cold Drink Container Paper Cup Production Line

    Buy cheap Double Wall Hot And Cold Drink Container Paper Cup Production Line from wholesalers

    Buy cheap Double Wall Hot And Cold Drink Container Paper Cup Production Line from wholesalers
    • Buy cheap Double Wall Hot And Cold Drink Container Paper Cup Production Line from wholesalers
    • Buy cheap Double Wall Hot And Cold Drink Container Paper Cup Production Line from wholesalers
    • Buy cheap Double Wall Hot And Cold Drink Container Paper Cup Production Line from wholesalers

    Double Wall Hot And Cold Drink Container Paper Cup Production Line

    Ask Lasest Price
    Brand Name : Fect
    Model Number : PFD-16 paper cup production line
    Certification : CE
    Price : USD 13200- USD14000 / set
    Payment Terms : T/T, Western Union, L/C, , MoneyGram
    Supply Ability : 300Sets per Month double wall hot and cold drink container paper cup production line
    Delivery Time : 35 days after receiving payment
    • Product Details
    • Company Profile

    Double Wall Hot And Cold Drink Container Paper Cup Production Line

    Double Wall Hot And Cold Drink Container Paper Cup Production Line

    double wall hot and cold drink container paper cup production line is the machine automatically lubricates each part that needs to be lubricated through the copper pipe, no need worker spraying oil manually which greatly saves labor.
    The machine automatically lubricates each part that needs to be lubricated through the copper pipe, no need worker spraying oil manually which greatly saves labor. PLC control make the machine more intelligent, the control is more accurate, easier operation and the labor is greatly reduced

    Technical Parameters

    Type

    PFD-16 double wall hot and cold drink container paper cup production line

    Cup size:

    3-16 oz (other customized size)

    Production capacity

    70-90 pcs/minutes

    Power source:

    380V 50HZ( or customized )

    Suitable Material:

    180-350g/m2 (single or double-coated paper)

    Air source

    0.4-0.5 Mpa

    Total Power:

    4 KW

    Package size:

    2.25*1.45*1.95 m, 2500KG

    Packaging of cup collection

    1100*1000*1000 70kg

    H.S code for customs:

    8441309000

    Double Wall Hot And Cold Drink Container Paper Cup Production Line


    A: top diameter:
    Min 46mm---Max 100mm
    B: bottom diameter
    Min 35mm---Max 70mm
    C: total height
    Min 32mm---Max 135mm

    Double Wall Hot And Cold Drink Container Paper Cup Production LineDouble Wall Hot And Cold Drink Container Paper Cup Production LineDouble Wall Hot And Cold Drink Container Paper Cup Production Line

    Advantages

    1. Three times paper feeding.
    Paper can be well adjusted with three times feeding process, avoid the irregularity during folding paper fan.
    2. Photoelectric Sensor Detection
    The encoder and the Photoelectric Sensor control the machine at the same time, one paper fan match one bottom to avoid paper waste. Failure alarm, automatic shutdown.
    3. PLC control
    The machine is more intelligent, the control is more accurate, easier operation and the labor is greatly reduced
    4. Multiple cooling fans for heat dissipation
    Multiple cooling fans installed to increase heat dissipation and speed up cooling, ensuring that the machine keep suitable temperature when working.

    Company Information


    Zhengzhou Perfect Co., Ltd. specialize in producing paper cup machine, high cup machine, paper bowl machine, paper box machine, dining box machine and other paper packaging equipments. Our company integrates research and development, production, sales and maintenance, constantly introducing new and high technology, focusing on after-sales service.

    With a wide range, good quality, reasonable prices and stylish designs, our products are extensively used in industry, food and other industries and are widely recognized and trusted by users and can meet continuously changing economic and social needs.

    We welcome new and old customers from all walks of life to contact us for future business relationships and mutual success!

    FAQ♦

    Q1: Delivery of Automatic Disposable Pe Coated Coffee Paper Cup Machine?

    A: Within 35 days after payment confirmed.

    Q2: Do you have relevant certificate?

    A: Yes, so far, we have CE, ISO, etc. we also can issue CO, Form E, etc if you need.

    Q3: How about the warranty and after-sale service?

    A: Our machines have two years warranty and lifetime technical support. Help is always just one call or email, and then we can provide a suitable solution within 8 hours after analyzing and estimating the problem.
